D-LINK Switch 24x1000Mbps (24xPOE) + 4xGigabit kombó SFP Menedzselhető Rackes, DGS-1210-24P/E
115 493 Ft

D-LINK Switch 24x1000Mbps (24xPOE) + 4xGigabit kombó SFP Menedzselhető Rackes, DGS-1210-24P/E

Szállítási idő
3 munkanap
Garancia
60 hónap
Raktáron   (5 db)
115 493 Ft
Hitelkalkulátor
Részletek

Specification

D-Link Web Smart DGS-1210-24P - switch - 24 ports - Managed - rack-mountable
Device TypeSwitch - 24 ports - Managed
Enclosure TypeRack-mountable 1U
SubtypeGigabit Ethernet
Ports12 x 10/100/1000 + 12 x 10/100/1000 (PoE+) + 4 x Gigabit SFP
Power Over Ethernet (PoE)PoE+
PoE Budget193 W
PerformanceSwitching capacity: 56 Gbps ¦ Forwarding performance: 41.7 Mpps
MAC Address Table Size16K entries
Remote Management ProtocolSNMP 1, SNMP 2, Telnet, SNMP 3, SNMP 2c, HTTP, CLI
FeaturesFlow control, Layer 2 switching, auto-negotiation, BOOTP support, ARP support, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, Syslog support, port mirroring, Weighted Round Robin (WRR) queuing, store and forward, Broadcast Storm Control, IPv6 support, half duplex mode, full duplex mode, Multicast Storm Control, Unicast Storm Control, firmware upgradable, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Access Control List (ACL) support, Quality of Service (QoS), Safeguard Engine, reset button, Cable Diagnostics Function, bandwidth control, D-Link Green Technology, LLDP support, Link Aggregation Control Protocol (LACP), DHCP client, Energy Efficient Ethernet
Compliant StandardsIEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3at
PowerAC 120/230 V (50/60 Hz)
Dimensions (WxDxH)44.1 cm x 20.99 cm x 4.4 cm
Weight2.28 kg






Extended Specification

General
Compliant StandardsIEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3at
Device TypeSwitch - 24 ports - Managed
Enclosure TypeDesktop, rack-mountable 1U
FeaturesFlow control, Layer 2 switching, auto-negotiation, BOOTP support, ARP support, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, Syslog support, port mirroring, Weighted Round Robin (WRR) queuing, store and forward, Broadcast Storm Control, IPv6 support, half duplex mode, full duplex mode, Multicast Storm Control, Unicast Storm Control, firmware upgradable, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Access Control List (ACL) support, Quality of Service (QoS), Safeguard Engine, reset button, Cable Diagnostics Function, bandwidth control, D-Link Green Technology, LLDP support, Link Aggregation Control Protocol (LACP), DHCP client, Energy Efficient Ethernet
MAC Address Table Size16K entries
PerformanceSwitching capacity: 56 Gbps ¦ Forwarding performance: 41.7 Mpps
PoE Budget193 W
Ports12 x 10/100/1000 + 12 x 10/100/1000 (PoE+) + 4 x Gigabit SFP
Power Over Ethernet (PoE)PoE+
Remote Management ProtocolSNMP 1, SNMP 2, Telnet, SNMP 3, SNMP 2c, HTTP, CLI
Status IndicatorsPort transmission speed, power, PoE, link/activity, fan
SubtypeGigabit Ethernet
Dimensions & Weight
Depth20.99 cm
Height4.4 cm
Weight2.28 kg
Width44.1 cm
Environmental Parameters
Humidity Range Operating0 - 95%
Humidity Range Storage0 - 95%
Max Operating Temperature50 °C
Max Storage Temperature70 °C
Min Operating Temperature-5 °C
Min Storage Temperature-20 °C
Expansion / Connectivity
Interfaces12 x 1000Base-T RJ-45 PoE+ - 30 W ¦ 12 x 1000Base-T RJ-45 ¦ 4 x SFP (mini-GBIC)
Miscellaneous
Compliant StandardsFCC Class A certified, C-Tick, BSMI, cUL, ICES-003, VCCI Class A
Power
Power DeviceInternal power supply
Voltage RequiredAC 120/230 V (50/60 Hz)

Adatok
EAN kód
790069391965
Gyártó
DLINK
Menedzselhető
Van
Gyártói Cikkszám
DGS-1210-24P/E
Áteresztő képesség
41,7000000
PoE (Power over Ethernet)
Van
Menedzselhetőség
Teljes
Cikkszám
TBY007615
Tömeg
3,7 kg/db
